【SPECIFICATIONS】
Poles; 1、2、3
Applicable wires; AWG24#~ 18#
Applicable PC board thickness: 1.6mm
Temperature range: -259C~85C
Voltage rating: 250V.AC/DC
Current rating: 7A
Contact resistance; ≤0.012
Insulation resistance: ≥1000MQ
Withstand voltage: 1500V.AC/1min
【MATERIAL】
Housing : PA66 UL94V-2(0)
Wafer: PA66 UL94V-2(0)
Terminal: Phos bronze Tin/plated
